ASUS Prime B760M-K DDR5
Sku: PRIME-B760M-K-DDR5
Availability: In Stock
Brand: asus
Categories: motherboard
₹0
Micro-ATX motherboard with Intel B760 chipset, supporting DDR5 memory, PCIe 4.0, dual M.2 slots, and Realtek 2.5Gb Ethernet.
Description:
The ASUS Prime B760M-K DDR5 is a compact and powerful micro-ATX motherboard engineered for Intel’s 12th, 13th, and 14th Gen Core processors. Designed to support the latest DDR5 memory technology, it delivers faster speeds and improved bandwidth for next-gen computing. With dual M.2 PCIe 4.0 slots for high-speed storage, Realtek 2.5Gb Ethernet for enhanced networking, and robust power delivery systems, this board ensures stability and performance. Built-in HDMI and VGA outputs, Fan Xpert cooling controls, and comprehensive protection features make it ideal for modern budget-to-mid-range PC builds.
Technical Specifications:
Specification | Details |
|---|---|
Form Factor | Micro-ATX |
Chipset | Intel B760 |
CPU Socket | LGA 1700 |
Supported CPUs | 12th, 13th, and 14th Gen Intel Core / Pentium / Celeron Processors |
Memory Support | 2 x DDR5 DIMM slots, up to 96GB, up to 7200+(OC) MHz |
Expansion Slots | 1 x PCIe 4.0 x16, 2 x PCIe 4.0 x1 |
Storage Options | 2 x M.2 PCIe 4.0 x4, 4 x SATA 6Gb/s |
Graphics Outputs | 1 x HDMI 2.1, 1 x VGA |
Networking | Realtek 2.5Gb Ethernet |
USB Ports (Rear I/O) | 2 x USB 3.2 Gen 1, 4 x USB 2.0 |
Audio | Realtek 7.1 Channel HD Audio |
Internal Connectors | USB 3.2 Gen 1 header, USB 2.0 headers, Front panel audio, RGB headers |
Cooling Features | VRM heatsink, PCH heatsink, hybrid fan headers, Fan Xpert 2+ |
Power Phase Design | 8+1 DrMOS Power Stages |
RGB Support | ASUS Aura Sync |
Operating System | Windows 11 / 10 64-bit |
Dimensions | 24.4 cm x 24.4 cm (9.6 in x 9.6 in) |
Warranty: 3 years
